OPS MODULE LUXVIEW OPSI5

Technical Specifications

CPU: Intel® Core™ i5-1240P (12 Cores / 16 Threads)
Chipset: Intel® SoC
Base Frequency: 1.7 GHz
RAM: 8 GB (Supports up to 32 GB)
Storage (SSD): 256 GB (Supports up to 512 GB)
Graphics: Intel® Iris® Xe Graphics
Wireless Network: 1 × M.2 2230 PCIe/USB Interface
Sound Card: ALC269 Sound Decoding Chip

LUXVIEW OPS-I5 WINDOWS MODULE

Product Description

The Luxview OPS-I5 is a high-performance OPS (Open Pluggable Specification) computer module designed to seamlessly integrate with interactive flat panels, smart displays, and digital signage systems.
Powered by the Intel® Core™ i5-1240P processor with 12 cores and 16 threads, it delivers exceptional multitasking performance and smooth operation for professional environments such as corporate meeting rooms, classrooms, and control centers.
Featuring Intel® Iris® Xe Graphics, expandable memory and storage, and a full range of I/O ports including HDMI, DP, USB Type-C, and RJ45, the OPS-I5 provides robust computing capabilities in a compact, plug-and-play design that eliminates external PCs and messy cabling.

Main Features

  • Intel® Core™ i5-1240P CPU with 12 cores and 16 threads for superior multitasking.

  • Intel® Iris® Xe Graphics ensures stunning 4K video output and high-quality visuals.

  • Supports up to 32 GB RAM and 512 GB SSD for flexible system expansion.

  • Comprehensive connectivity with USB 3.0, USB-C, HDMI, DP, and RJ45 interfaces.

  • Compact OPS form factor for seamless integration with compatible displays.

  • Dual-band Wi-Fi and Bluetooth support for wireless communication.

  • Windows 10/11 (64-bit) system ready (license not included).

  • Industrial-grade reliability, capable of 24/7 operation in various environments.

    I/O Interfaces

    • 4 × USB 3.0

    • 1 × USB Type-C

    • 1 × MIC IN

    • 1 × LINE OUT

    • 1 × HDMI OUT

    • 1 × DP OUT

    • 1 × RJ45 LAN

    • 1 × Power Indicator Light

    • 1 × Power Button

    • 2 × Antenna Ports

    • 1 × One-Touch Restore Button

    OPS 80-Pin Interface

    • 1 × HDMI 2.0

    • 1 × DP

    • 3 × USB 2.0

    • 1 × USB 3.0

    • DC Power Input

    Power

    • Input Voltage: 12 – 19 V DC

    • Maximum Power Consumption: 80.7 W

    Physical Characteristics

    • Dimensions: 180 × 119 × 30 mm

    • Operating System: Windows 10 / 11 (64-bit, license not included)

    Environmental Conditions

    • Operating Temperature: -10 °C ~ 45 °C

    • Operating Humidity: 10 % ~ 90 % RH (non-condensing)

    • Storage Temperature: -20 °C ~ 60 °C

    Applications

    • Interactive flat panels and smart classrooms

    • Corporate meeting rooms and video conferencing systems

    • Digital signage and control centers

    • Training centers and collaboration environments
